Intelligent Automatic Box Corner Pasting Machine For Rigid Box, Gift Box Producing
Automatic Paper Box Making Machine Parameters:
| Model |
ZY-450C |
| Max. size of box |
450*400*140mm |
| Min. size of box |
45*45*8mm |
| Folding-in Depth |
140mm |
| Power consumption |
2.5KW |
| Speed |
50-90pcs/min |
| Voltage |
AC220V |
| Air consumption |
8L/min 0.8Mpa |
| Weight |
1200kg |
| Measurement |
1100x1800x1900mm |
Introduction of ZY-450C Automatic Corner Pasting Machine:
The ZY-450C automatic corner pasting machine can unload the box in three directions, and can be combined accoding to the production to requirements, saving production space. This machine is different from the leakage hazard of the 220V heating module of the traditional corning machine. It is first to use the 24V low voltage heating module to prevent the leakage accident caused by the friction of the head. The machine gradually replaces the traditional manual conering with advantages of fast production speed, stable cornering and low cost. It greatly improves production efficiency and saves a large munber of personnel. It is widely used in carton cover packaging enterprises.
Application range:
Mobile phone case, underwear box, gift box, food box, plastic box
This machine is designed for packaging boxes, such as jewellery box, gift box, mobile box, tea box,etc.
All of the relevant products are internationally high-end products, low breakdown, high accuracy.
Primary products:
Automatic Rigid Box Making Machine
Automatic Paper Box Making Machine
Jewellery Box Making Machine
Box Forming Machine
Box Assembly Machine
Corner Pasting Machine
Paper Gluing Machine
Automatic Grooving Machine
Etc.
About Us:
QC Profile
The whole production procedure will be under regular inspection and strict quality control.
The complete machine will be tested to make sure they can work very well before being out of factory.
The testing video and pictures will be available before delivery.
Continuous research and development of the user's technology and production processes, in order to ensure product quality, our company has advanced testing equipment and improve the management system, we will provide better products and the best service to customers.
